27x Optical Zoom Camera

Model No VC 1227
Signal model PAL/NTSC
Image sensor 1/4″ SONY EFFIO CCD
Effective pixel 752(Horizontal)x 582(Vertical)
Horizontal resolution 480TVL
Minimum illumination Color:0.01Lux B/W:0.001Lux / 0Lux
Infrared sensor Yes

• 480 TVL 27 X Sony Optical Zoom
• Quick auto focus.
• Auto IRIS.
• Low illumination 0.01LUX
• 1/4 Sony super HAD CCD
• Built in Auto Focus/Auto Iris
• OSD(ON Screen Display)
• RS485 control, inside RS485 decoder, use pelco-D or pelco-P
protocol to connect with DVR or Keyboard Controller

Color to B/W Yes
Sync system Internal sync
Focus length 3.2~86.4mm
Optical focus 27X
Focus Auto/manual, take high-performance DSP to
realize complete digit and ultra-high speed
focus function
Gain Control Auto/Manual
White balance Auto
Iris Auto
S/N radio >60dB(Enhanced)
Electronic shutter 1/50~1/120000 seconds
Video output 1.0Vp-p 75 ohm
Power cut memory restore Yes
Language English
Screen menu Address code、gain control、backlight
compensate、electronic shutter
Control RS485/by wire、baud rate (2400/4800/9600)
optional, build-in PELCO-D protocol
Gama modulus 0.45
Power supply DC12V,130~350mA
Work temperature 0 C~+70 C
Dimension 62mmX72mmX118mm
